opzv vrla MERITSUN Brand vrla gel battery factory
1. The newly launched products by MeriTech Power Co.,Ltd. were all completed by the internationally renowned design company. Its long cycle life with over 2000 cycles helps owners reduce replacement cost
2. All relative certificates to guarantee quality will be provided by MeriTech Power Co.,Ltd.. The weight of the product is about 40% of the weight of a comparable lead-acid battery
3. opzv battery provides premium presentation of vrla gel battery due to opzs batterie design. The product is produced under the principle of environmental protection.
4. The outstanding performance of the product meets the specific applications. It can be widely applied in diverse areas ranging from small appliances and IT devices
❈ Product Features
★ General Features：
◪1. Using oxygen recombination technology: maintenance-free
◪2. Special grid alloy: less gassing, less self-discharging
◪3. For longer cycle life: special paste formula, over dimensioned negative plate, optimised manufacturing process , additives for deep discharge
◪4. Thermal management system (optional)
◪5. Special anti-vibration design (optional)
◪6. High quality AGM separator: extend cycle life
◪7. ABS material: increase the strength of battery container. (Flame-retardant ABS is optional)
❈ Typical Applications
| Electric tools | Portable apparatus, lights and instruments | Portable power |
| Vehicle in place of walking | Electric toys | Wheelchairs |
| Lawn mowers | Illumination light | Medical equipments |
| Golf trolleys and golf cart | Fire alarms | |
❈ Product Specification
Model | Rated Voltage (V) | Rated Capacity (Ah) | Approx Dimension | Approx Weight | Terminal Type | ||||||||
Length | Width | Height | Total Height | ||||||||||
mm | inch | mm | inch | mm | inch | mm | inch | kg | lbs | ||||
GD100-2 | 2 | 100 | 170 | 6.69 | 72 | 2.83 | 205 | 8.07 | 212 | 8.35 | 5.75 | 12.68 | T6 |
GD200-2 | 2 | 200 | 170 | 6.69 | 110 | 4.33 | 328 | 12.9 | 350 | 13.78 | 12.0 | 26.46 | T11 |
GD300-2 | 2 | 300 | 170 | 6.69 | 150 | 5.91 | 328 | 12.9 | 350 | 13.78 | 16.8 | 37.04 | T11 |
GD400-2 | 2 | 400 | 210 | 8.27 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 22.4 | 49.38 | T11 |
GD500-2 | 2 | 500 | 240 | 9.45 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 26.7 | 58.86 | T11 |
GD600-2 | 2 | 600 | 300 | 11.81 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 34.0 | 74.96 | T11 |
GD800-2 | 2 | 800 | 410 | 16.14 | 175 | 6.89 | 330 | 13.0 | 350 | 13.78 | 48.2 | 106.3 | T11 |
GD1000-2 | 2 | 1000 | 475 | 18.70 | 175 | 6.89 | 328 | 12.9 | 350 | 13.78 | 55.6 | 122.6 | T11 |
GD1500-2 | 2 | 1500 | 403 | 15.87 | 354 | 13.94 | 339 | 13.4 | 350 | 13.78 | 94.0 | 207.2 | T11 |
GD2000-2 | 2 | 2000 | 490 | 19.29 | 350 | 13.78 | 339 | 13.4 | 350 | 13.78 | 112.9 | 248.9 | T11 |
GD3000-2 | 2 | 3000 | 712 | 28.03 | 350 | 13.78 | 339 | 13.4 | 350 | 13.78 | 169.1 | 372.8 | T11 |
GD5.6-6 | 6 | 5.6 | 70 | 2.76 | 47 | 1.85 | 100 | 3.94 | 103 | 4.17 | 0.93 | 20.5 | T1/T2 |
GD13-6 | 6 | 13 | 151 | 5.94 | 51 | 2.01 | 94 | 3.70 | 100 | 3.94 | 2.03 | 4.52 | T1/T2 |
GD3.5-12 | 12 | 3.5 | 134 | 5.28 | 67 | 2.64 | 60.5 | 2.38 | 66.5 | 2.62 | 1.36 | 3.00 | T1 |
GD5.6-12 | 12 | 5.6 | 90 | 3.54 | 70 | 2.76 | 101 | 3.98 | 107 | 4.21 | 1.74 | 3.84 | T1/T2 |
GD7.2-12 | 12 | 7.2 | 151 | 5.94 | 65 | 2.56 | 94.5 | 3.72 | 99.5 | 3.92 | 2.50 | 5.51 | T1/T2 |
GD8-12 | 12 | 8 | 151 | 5.94 | 65 | 2.56 | 94.5 | 3.72 | 99.5 | 3.92 | 2.45 | 5.40 | T1/T2 |
GD12-12 | 12 | 12 | 151 | 5.94 | 98 | 3.86 | 95 | 3.74 | 101 | 3.98 | 4.00 | 8.82 | T1/T2 |
GD17-12 | 12 | 17 | 181 | 7.13 | 76 | 2.99 | 167 | 6.57 | 167 | 6.58 | 5.90 | 13.01 | T3 |
GD24-12 | 12 | 24 | 165 | 6.50 | 125 | 4.92 | 175 | 6.89 | 182 | 7.17 | 8.40 | 18.52 | T3/T10/T12 |
GD33-12 | 12 | 33 | 195 | 7.68 | 130 | 5.12 | 155 | 6.10 | 180 | 7.09 | 9.60 | 21.16 | T5/T6/T12 |
GD38-12 | 12 | 38 | 197 | 7.76 | 165 | 6.50 | 176 | 6.93 | 182 | 7.17 | 12.7 | 27.99 | T5/T6/T12 |
GD55-12 | 12 | 55 | 231 | 9.09 | 139 | 5.47 | 208 | 8.19 | 225 | 8.86 | 14.7 | 32.41 | T6/T9/T14 |
GD65-12 | 12 | 65 | 348 | 13.70 | 166 | 6.54 | 178 | 7.01 | 178 | 7.01 | 19.5 | 42.99 | T6 |
GD80-12 | 12 | 80 | 348 | 13.70 | 166 | 6.54 | 178 | 7.01 | 178 | 7.01 | 21.6 | 47.62 | T6 |
GD90-12 | 12 | 90 | 306 | 12.05 | 168 | 6.61 | 210 | 8.27 | 230 | 9.06 | 25.0 | 55.12 | T6/T9 |
GD100-12A | 12 | 100 | 329 | 12.95 | 171 | 6.73 | 214 | 8.43 | 220 | 8.66 | 29.5 | 65.04 | T11 |
GD100-12B | 12 | 100 | 407 | 16.02 | 174 | 6.85 | 208 | 8.19 | 233 | 9.17 | 31.0 | 68.34 | T11 |
GD120-12 | 12 | 120 | 407 | 16.02 | 174 | 6.85 | 208 | 8.19 | 233 | 9.17 | 32.4 | 71.43 | T11 |
GD150-12 | 12 | 150 | 483 | 19.02 | 170 | 6.69 | 239 | 9.41 | 240 | 9.45 | 41.5 | 91.49 | T11 |
GD200-12 | 12 | 200 | 522 | 20.55 | 239 | 9.41 | 218 | 8.58 | 224 | 8.82 | 56.2 | 123.9 | T11 |
GD250-12 | 12 | 250 | 522 | 20.55 | 268 | 10.55 | 218 | 8.58 | 226 | 8.90 | 71.0 | 156.5 | T11 |
★ Specification subject to change without prior notice.
Please fill in the detailed requirements in the "Leave a Message" below, customer service will provide you with the latest product information, and the best design solution for FREE!
Company Features
1. MeriTech Power Co.,Ltd. is active in opzv battery market with advantages of technology and vrla gel battery.
2. Please Contact Us! MERITSUN's opzs battery, opzs batterie, gel batteries for sale Have The Features Of High Efficient And Low Priced. We Are Willing To Enter Into Business Relations With Your Firm On The Basis Of Equality And Mutual Benefit.
3. The friendly cooperation with sealed gel battery helps the growth of MERITSUN. Inquire online!
